EXM-40A PLC expansion modul has got 14 bit resolution 4 analog inputs capacity. Analog input types setting are madeover EndaSoft software ad there is no necessary to make any jumper setting.
| Technical Specifications |
| Power Supply |
Internal (Occurs via the PLC Bus) |
| Power Consumption |
24VDC Max. 2W. |
| Mounting type |
Mounted on CPU BUS to DIN RAY |
| Analog input channels |
| Number |
Total 4 independent analog input channels |
| Resolution |
14 Bit resolution (0…16383) measurement |
| Input type |
0-10VDC, 0-20mA or 4-20mA. (Selectable from software) |
| Accuracy |
±%0.5 |
| Read speed |
A reading for each cycle of PLC |
| Environmental Conditions |
| Sıcaklık |
-10…+60 °C (Without icing) |
| Nem |
5…95% relative humidity |
|
|
|
